Aeonmed Shangrila 510s Invasive Ventilator

$
19,890
$
Wholesale request

Ventilator is a pneumatically driven electrically controlled machine. It can provide patients with mechanical ventilation, and also can monitor and display of ventilation parameters. The Ventilator is controlled by microprocessor, equipped with model parameters and waveform monitor, capacity and other optional functions.

At this time, Adonyss Medical is taking preorders only on all ICU Ventilators. Production time is currently three weeks to two months.

Please note that the sooner your order is placed, the sooner you can expect to receive your equipment.
Need help?
Have our experts call you. Call Me
Shipping:

Express: 7-14 days
Standart: 25-45 days
Portable Ventilator
Ventilator is mainly used in the emergency rooms of hospitals, transfer after operations, field and occasions where first-aid or transfer is needed,for care of adult ,pediatric , infant patients weighing at least 3.5 kg.

Shangrila 510S is a universally used model. Not only for emergency ventilation, but also it is suitable for ideal transport ventilation. The circumstances include on-site emergency treatment, pre-hospital transport, interhospital transport, and even intra-hospital transport.
Technical Parameters

Patient Type
Adult, Child, Infant (>3.5 kg)

Ventilation Modes
A/C-V with Sigh - A/C-P
SIMV-V - SIMV-P
SPONT/PSV - CPAP
MANUAL

Enhancements
Apnea back-up ventilation - Manual breath
Alarm silence

Parameter Setting
Tidal volume - (Vt) 0-2000 mL
Pinsp - 5-50 cmH2O
Psupp - 0-50 cmH2O
CPAP (NIV) - 0-30 cmH2O
PEEP - 0-30 cmH2O
Pressure trigger: -20-0 cmH2O
Flow trigger - 2-30 L/min
Frequency - (f) 1-120 bpm (A/C) / 1-40 bpm (SIMV)
I:E ratio - 4:1-1:10
Pause time (Tpause) - 0-5 s
O2 concentration - 40-100 %
Inspiration flow - Max. 90 L/min

Monitoring Data
MV - VT - Frequency (f)
FiO2 - Ppeak - PEEP

Waveform Display
P-T / F-T

Alarm Setting
High MV - OFF, 1-25 L
Low MV - OFF, 0-24 L
High FiO2 - OFF, 50-100 %
Low FiO2 - OFF, 35-99 %
High Paw - 6-80 cmH₂O
Low Paw - 0-40 cmH₂O
AC power failure - Gas supply down
O2 deficiency - MV high
Low battery - No VT
Apnea - CP high

Language
Electrical - Chinese - English - Spanish - Italian - Other languages

Electrical
AC voltage - 100-240 V, 50/60 Hz
DC voltage - 12 V
One battery run time - Minimum 4.5 hours
Two batteries run time - Minimum 10 hours

Gas Supply
Supply pressure - (O2) 250-600 kPa
Flow - Max. 180 L/min

Environmental Requirements
Temperature
Operating condition: -18-50 oC
Storage condition: -20-60 oC

Relative humidity
Operating condition - 15-95 %
Storage condition 10-95 %

Barometric pressure
Operating condition 70-110 KPa
Storage condition 50-110 KPa

Physical Specifications
Total Weight - 8 kg
Dimension (H*W*D): 168* 156 *300 mm
LCD screen - 5" TFT
Communication Ports - RS232
